PRODUCT TECHNICAL SPECIFICATIONS
Session Area: 745x360x600 cm
Security Zone: 935x600 cm
Age Range: 2-12 years
PRODUCT SPARE PARTS
-POLYETHYLENE SHIP NOSE KIT – 1 PIECE
-POLYETHYLENE SHIP PANEL – 1 PIECE
-COMPOSITE LADDER - 1 PIECE
-STAIR RAILING – 1 PIECE
-POLYETHYLENE LANDING PANEL – 5 PIECES
-METAL CLIMBING ENTRY – 1 PIECE
-H:150 cm UFO CLIMBING ELEMENT – 1 PIECE
-METAL SLIDE RAILING – 1 PIECE
-POLYETHYLENE SQUARE ROOF – 1 PIECE
-POLYETHYLENE SHIP FIGURE – 1 PIECE
-POLYETHYLENE BIRD FIGURE - 1 PIECE
-H:150 cm SPIRAL SLIDE – 1 PIECE
-POLYETHYLENE SEAT PANEL RAILING – 1 PIECE
-H:150 cm TOWER PIPE – 6 PIECES
-116X116 COMPOSITE SQUARE PLATFORM - 2 PIECES
POLYETHYLENE PRODUCTS
Low or common density linear polyethylene (LLDPE-Linear Low Density Polyethylene) is a thermoplastic used in various products.
Semi It is a permeable, softenable and highly durable polymer, and is a highly preferred product in the industry due to its low cost and high resistance. Polyethylene is classified into various categories based on its density and chemical properties.
Its mechanical properties depend on its molecular weight, crystal structure and branching type. Although its properties vary depending on the type; good resistance to external environmental conditions and humidity, flexibility, weak mechanical strength and superior chemical resistance can be counted as general properties. Polyethylene products are used in the production of slides, stairs, railings, barriers, accessories, roofs etc.
In order to prevent color fading in polyethylene products, the ''Light Fastness'' test value of masterbatch dyes used to color polyethylene products should be 6 or above.
The product wall thickness should be minimum 6 mm at points exposed to pressure and friction, and minimum 4 mm in barrier and shade products that are not exposed to any pressure. The material should be distributed equally and create equal thickness. The wall thickness of the products and the deviation tolerance of the dimensions are 5%.
BEARING CONSTRUCTION
It will be made of circular section steel pipes with a minimum diameter of 114 mm and a minimum wall thickness of 2 mm, cold formed and welded with high frequency welding in accordance with TS EN 10219-2, TS-6476, DIN 2394 standards, and manufactured within the tolerance, dimension and section measurement range in the standard. This bearing construction will be made of pipes painted by baking with polyester-based electrostatic powder oven paint over sandblasting.
ELECTROSTATIC POWDER OVEN PAINT
In order to remove oil, dirt and rust that will prevent painting on all metal parts, the pores on the material will be opened with the sandblasting method, which is the most effective method, and the material will be made ready for painting in order to hold the paint better. ,
It will be done by spraying the fine ball material filled into a pressure-resistant cabin with pressurized air to open the pores where the paint will hold and to remove the oil, rust and dirt on the metal material.
After all the metal parts are manufactured, they will be coated with polyester-based electrostatic paint and then baked in an oven at 200-220 degrees for 20 minutes to complete the painting process.
After all the metal parts are manufactured, they will first be rinsed in a 5% concentration degreasing bath at 70 degrees for 10 minutes and then immersed in a 1% concentration iron bath at 50 degrees for 15 minutes.
Then, rinsing and drying processes will be carried out again, the material will be coated with durable polyester-based powder paint for electrostatic system exteriors and baked in ovens at 180-200 degrees for 20-30 minutes to complete the painting process. The entire product will be painted as a single piece after welding to prevent the welded areas from rusting.
