PRODUCT TECHNICAL SPECIFICATIONS
Age Range: 2-5 years
Fall Height: 120 cm
Safety Zone: 102 m2
PRODUCT SPARE PARTS
-POLYETHYLENE SHIP NOSE KIT – 1 PIECE
-POLYETHYLENE SHIP PANEL – 3 PIECES
-POLYETHYLENE LANDING BARRIER – 4 PIECES
-H:100cm TOWER PIPE – 9 PIECES
-METAL CLIMBING ENTRY – 1 PIECE
-METAL CLIMBING ELEMENT – 1 PIECE
-H:100 cm WAVE SLIDE – 2 PIECES
-COMPOSITE STAIRCASE - 1 PIECE
-METAL STAIRCASE RAILING – 1 PIECE
-POLYETHYLENE BIRD FIGURE – 1 PIECE
-POLYETHYLENE SHIP FIGURE – 1 PIECE
-116X116 COMPOSITE SQUARE PLATFORM - 4 PIECES
POLYETHYLENE PRODUCTS
Low or common density linear polyethylene (LLDPE-Linear Low Density Polyethylene) is a thermoplastic used in various products.
While it is a semi-permeable, softenable and quite durable polymer, it is a highly preferred product in the industry due to its low cost and high resistance. Polyethylene is classified in various categories based on its density and chemical properties.
Its mechanical properties depend on its molecular weight, crystal structure and branching type. Although its properties vary according to types; good resistance to external environmental conditions and moisture, flexibility, weak mechanical strength and superior chemical resistance can be counted as general features. Polyethylene products are used in the production of slides, stairs, railings, barriers, accessories, roofs etc.
In order to prevent color fading in polyethylene products, the ''Light Fastness'' test value of masterbatch dyes used to color polyethylene products should be 6 or above.
Product wall thickness should be minimum 6 mm at points exposed to pressure and friction, and minimum 4 mm in barrier and shade products that are not exposed to any pressure. The material should be distributed evenly and create equal thickness. The deviation tolerance of the wall thicknesses and dimensions of the products is 5%.
BEARING CONSTRUCTION
Minimum 114 mm. diameter minimum 2 mm wall thickness, in accordance with TS EN 10219-2, TS-6476, DIN 2394 standards, cold formed and welded with high frequency welding, manufactured within the tolerance, size and section size range specified in the standard; will consist of circular cross-section steel pipes. This carrier construction will consist of pipes painted by baking with polyester-based electrostatic powder oven paint over sandblasting.
ELECTROSTATIC POWDER OVEN PAINT
Oil that will prevent painting on all metal parts,The most effective method for removing dirt and rust is to use sandblasting to open pores on the material and make it ready for painting so that the paint can adhere better. ,
It will be done by spraying the fine ball material filled into a pressure-resistant cabin with pressurized air to open the pores where the paint will hold and to remove the oil, rust and dirt on the metal material.
After all the metal parts are manufactured, they will be coated with polyester-based electrostatic paint and then baked in an oven at 200-220 degrees for 20 minutes to complete the painting process.
After all the metal parts are manufactured, they will first be rinsed in a 5% concentration degreasing bath at 70 degrees for 10 minutes and then immersed in a 1% concentration iron bath at 50 degrees for 15 minutes.
Then, rinsing and drying processes will be carried out again, the material will be coated with durable polyester-based powder paint for electrostatic system exteriors and baked in ovens at 180-200 degrees for 20-30 minutes to complete the painting process. The entire product will be painted as a single piece after welding to prevent the welded areas from rusting.
