PRODUCT TECHNICAL SPECIFICATIONS
Usage Area: 438x1325 cm
Safe Area: 442x1330 cm
User Age: +5 years old
Capacity: 10-16 people
Material: LLDPE
Metal parts: Galvanized steel
Connection element and clamps: Aluminum alloy
Nylon net consists of six steel cables with a total diameter of 16 mm in the center.
Function: Climbing activities strengthen the arms and legs, coordinate the body and improve balance.
PRODUCT SPARE PARTS
-H:245cm SINGLE ROW GRAVEL BRIDGE - 1 PIECE
-H:245cm SINGLE PILLAR OVERHEAD PARALLEL BAR CLIMBING ELEMENT – 1 PIECE
-H: 245cm SINGLE PILLAR INCLINED GRAVEL BRIDGE – 1 PIECE
-H: 60cm SINGLE PEBBLE – 6 PIECES
-H: 245cm TORONTO PASSAGE CLIMBING ELEMENT – 1 PIECE
POLYETHYLENE PRODUCTS
Low or common density linear polyethylene (LLDPE) is a thermoplastic used in various products.
While it is a semi-permeable, softenable and highly durable polymer, it is a highly preferred product in the industry due to its low cost and high resistance. Polyethylene is classified in various categories based on its density and chemical properties.
Its mechanical properties depend on its molecular weight, crystal structure and branching type. Although their properties vary depending on the type; good resistance to external environment conditions and moisture, flexibility, weak mechanical strength and superior chemical resistance can be counted as general properties. Polyethylene products are used in the production of slides, stairs, railings, barriers, accessories, roofs, etc.
In order to prevent color fading in polyethylene products, the ''Light Fastness'' test value of masterbatch dyes used to color polyethylene products should be 6 or above.
Product thickness should be minimum 6 mm at points exposed to pressure and friction, and minimum 4 mm in barrier and shade products that are not exposed to any pressure. The material should be distributed evenly and create equal thickness. The deviation tolerance of the wall thickness and dimensions of the products is 5%.
ELECTROSTATIC POWDER OVEN PAINT
In order to remove the oil, dirt and rust that will prevent painting on all metal parts, the pores will be opened on the material by the sandblasting method, which is the most effective method, and the material will be made ready for painting in order to hold the paint better. ,
It will be done by spraying the fine ball material filled in a pressure-resistant cabin with pressurized air to open the pores where the paint will hold and removing the oil, rust and dirt on the metal material.
After all metal parts are manufactured, they will be coated with polyester-based electrostatic paint and baked in an oven at 200-220 degrees for 20 minutes to complete the painting process.
After all metal parts are manufactured, they will first be rinsed in a 5% concentration degreasing bath at 70 degrees for 10 minutes and then immersed in a 1% concentration iron bath at 50 degrees for 15 minutes.
Then, rinsing and drying processes will be carried out again, the material will be coated with durable polyester-based powder paint for electrostatic system exteriors and baked in ovens at 180-200 degrees for 20-30 minutes to complete the painting process. In order to prevent rust, the entire product will be painted as a single piece after welding.
